Specificatii:


Frequency Response:
On Axis @ 0° ±3dB: 36 - 21,000Hz;
On Axis @ 0° ±1 1/2dB: 54 - 20,000Hz;
Off Axis @ 30° ±1 1/2dB: 54 - 10,000Hz;
LF Cutoff -10dB: 28Hz;

Sensitivity:
Anechoic Chamber: 88dB;
Listening Room: 90dB;

Impedance:
Nominal: 8 Ohms;
Minimum: 6 Ohms;

Input Power:
Recommended: 15 - 120 Watts;
Program: 60 Watts;

Acoustic Design:
Tweeter (Nominal): 3/4” (19mm)Black Anodized Aluminium Dome with Ferrofluid and Neodymium Magnet;
Woofer (Nominal): 2 x 5 1/4” (133mm) Textured Polypropylene Cone with Rubber Surround;

Crossover: 2,500Hz, L4;

Internal Volume: 0.95 cu ft (8.3L);

Design Type: Tuned Port Bass Reflex, 2 1/2” (63.5mm) Rear Port;

Dimensions / Weights:
Size (W x H x D): 6 3/4” x 32 1/2” x 9 3/8” (170 x 825 x 243mm);
Weight: 26.15lb (11.9kg)/each; 62.7lb (28.5kg)/pr.
