Receiver stereo Onkyo TX-8390

Specificatii:


Amplifier Section
Power output 200 W/Ch
(6 Ω, 1 kHz, 10%, 2 channels driven)
180 W/Ch
(6 Ω, 1 kHz, 1% THD, 2 channels driven, IEC)
Dynamic power 300 W (3 Ω, Front)
250 W (4 Ω, Front)
150 W (8 Ω, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz−20 kHz, half power)
Input sensitivity and impedance
200 mV rms/47 kΩ (Line)
Rated RCA output level and impedance
1 V rms/470 Ω (Pre-out/Zone 2 line-out)
Phono overload 70 mV (MM, 1 kHz, 0.5%)
Frequency response 10 Hz−100 kHz/+1 dB, -3 dB
(Direct Mode/Pure Audio)
Tone control ±10 dB, 20 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-noise ratio 106 dB (IHF-A, Line In, Speaker Out)
80 dB (IHF-A, Phono In, Speaker Out)
Speaker impedance A/B 4−16 Ω
A+B 8−16 Ω
Headphone output impedance
330 Ω
Headphone rated output 80 mW + 80 mW (32 Ω, 1 kHz, 10%)
Tuner Section
Tuning frequency range
FM/RDS 87.5−108 MHz
FM/DAB+ preset memory
40 Stations
General
Power supply AC 220−240 V~, 50/60 Hz
Power consumption 340 W
Standby power consumption
0.15 W
No-sound power consumption
45 W
Network standby power consumption
2.0 W
Dimensions (W x H x D) 435 x 174 x 383 mm
Weight 11.8 kg
CARTON
Dimensions (W x H x D) 435 x 174 x 383 mm
Weight 11.8 kg
Supplied Accessories
• DAB/FM antenna • Initial Setup Guide • Power cord
• Speaker setup microphone •
