Specificatii:


GENERAL SPECIFICATIONS:
All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter.

Continuous output power:
8 ohms: >80W / 100W (ref. 20 Hz-20 kHz at rated THD+N, both channels driven);
4 ohms: >100 W;

THD+N (20 Hz – 20 kHz) at rated power:
<0.04 % (250mW to 90W, 4 ohms);
<0.04 %;

Signal-to-Noise Ratio: >84 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms);

Clipping power:
>86 W (at 1 kHz 8 ohms 0.1 % THD);
>102 W (at 1 kHz 4 ohms 0.1 % THD);

IHF dynamic power:
8 ohms: 100 W;
4 ohms: 125 W;

Damping factor: >90 (ref. 8 ohms, 20Hz to 20kHz);

Frequency response: ±0.18 dB (20 Hz – 20 kHz);

Tone controls:
Treble: ±6.0 dB at 20 kHz;
Bass: ±6.0dB at 60 Hz;

Channel separation:
>93 dB (1 kHz);
>72 dB (10 kHz);

Input sensitivity (for 80 W in 8 ohms):
Line In: 550 mV;
Digital In: -12 %FS;
Standby power: >0.5W;

SUBWOOFER OUT:

Maximum output level: 4.0 Vrms (ref 0.0032% THD+N 100 Hz);

Signal-to-Noise ratio: >106 dB (20 Hz-20 kHz, ref 1V out);

THD+N: >0.006 % (20 Hz-200 Hz, ref 1.964V);

Output impedance: 600 ohms;

BluOS AUDIO
AUDIO:

Sampling rate: up to 32 bit/192 kHz PCM;

Bit depths: Bit depths 16 – 24;

CONNECTIVITY:

3rd Party integrations: Airplay 2;

Network connectivity:
Gigabit Ethernet RJ45;
Wi-Fi 5;

USB: 1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals;

Bluetooth quality: aptX HD;

Bluetooth connectivity: Two-Way (Receive and Headphone modes);

USER INTERFACE:

Supported operating system: Music playback from network shares on the following desktop operating systems: Microsoft;
Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions;

Mobile Application: Free BluOS Controller App available for download from the respective App stores of Apple;
iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops;

DIMENSION AND WEIGHT:

Gross dimensions (W x H x D): 218 x 96 x 266 mm;
8 5/8 x 3 13/16 x 10 1/2 inches;

Net Weight: 4.8 kg (10.6 lbs.);

Shipping weight: 5.3 kg (11.7 lbs).
