Specificatii:


Hybrid DAC with CD transport:

Valves:
4 X ECC83;

Digital Inputs:
1 x USB 2.0: 44.1 – 384 kHz , DSD128, DSD256 Ready Res: 16 to 32 bits;
1 x S/PDIF: 0.5Vpp on 75 Ohms, 44.1 -192 kHz, DSD64 (DoP) Res: 16 to 24 bits;
1x AES/EBU: 2Vpp on 110 Ohms, 44.1 -192 kHz, DSD64 (DoP) Res: 16 to 24 bits;
1 x Toslink™ : 44.1 – 96 Res.: 16 to 24 bits;
1 x Bluetooth™ 3.0 : 44.1, 48kHz Res: 16 bits;

Digital Output:
1x  S/PDIF 0.5Vpp on 75 Ohms;
1x  AES/EBU 2Vpp on 110 Ohms;
1x Toslink™;

Transport:
CD-Loader;

Display:
128 X 64 White OLED graphic display;

DAC:
ESS Sabre ES9018K2M SNR: 128dB (0dBFS, 1kHz, 192kHz, “A” weighted ) THD+N: 0.0003% (0dBFS, 1kHZ, 20Hz-20kHZ);

I/V Converter:
AD8597/AD8599 ultra low distortion and ultra low noise;

Valve Output Stage:

Number of channels:
2;

Output stage:
Duble Triode, pure class A differential Totem-pole;

Valve model:
4 x ECC83;

Output audio connectors:
2 x RCA, 2 x XLR;

Filters:
3 Digital Filters selectable by R.C.;
FLT 1: Fast Roll-Off, linear Phase;
FLT 2: Fast Roll-Off, minimum Phase;
FLT 3: Slow Roll-Off, linear Phase;

Solid state Output selectable:
Selectable absolute Phase;

Dimension:
45cm x 38cm x H 13cm;

Net weight:
10Kg / 22 lb.
