Specificatii:


Performance:
Nominal speed 33/45 rpm, outside belt drive system, manual speed change;
Speed Variance 33rpm: ± 0.30 %, 45rpm: ± 0.20 %;
Wow and flutter 33rpm: ± 0.10%, 45rpm: ± 0.09%;
Signal to noise ratio Mechanical noise: - 39 dB;
Electrical noise: -65dB;
Downforce range 0 - 25 mN;
Tonearm 9'' straight shape massive aluminium construction;
Supplied counterweights no. 82, weight 114g (± 1g), for cartridges from 5 to 13g;
Effective tonearm mass 14g;
Effective tonearm length 230mm (tonearm mounting distance 212mm);
Overhang 18mm;

Power:
Power requirement 15V 0.8A (Adaptor supplied);
Consumption >0.25 Watts standby 5 Watts maximum;
Adaptor mains voltage 110-240 V 50-60Hz;

Weight:
Unit only, unboxed 6 kg (131/5 lbs);
In shipping carton 8 kg (173/5 lbs)

Supplied Cartridge Ortofon 2M Red:
Cartridge type Moving Magnet;
Frequency Response 20 - 20.000 Hz + 3 / - 1 dB;
Channel Separation 22 dB at 1 kHz;
Channel Balance 1.5 dB;
Tracking Force 1.6 - 2.0g (1.8g recommended);
Vertical Tracking Angle 20°;
Recommended Load Impedance 47,000 ohms;
Recommended Load Capacitance 150 - 300pF;
Output Voltage 5.5 mV (mV at 1 kHz, 5 cm/sec);
Stylus Shape Elliptical;
Stylus Construction tipped Elliptical diamond;
Mount Half-inch;
Weight 7.2g;
Replacement Stylus 2M Red (exchangeable with 2M Blue and 2M Silver);

Dimensions:
Width 542 mm (23½”);
Height (including feet) 100 mm (4”);
Depth (front to back) Inc. terminals 342 mm (13½”);
