Specificatii: DAC XLR:
THD+N @1kHz (A-wt): <0.00007%
THD @20-20kHz 90kBw: <0.00015%

SNR @1kHz (A-wt): 131dB
Dynamic Range @1kHz (A-wt): 131dB

Frequency Response: 20Hz-20kHz (‡0.2dB) / 20Hz-40kHz (±0.6dB)
Output Level: 4.2Vrms @0dBFS
Noise (A-wt): <1.3uVrms

Channel Crosstalk: -125dB @1kHz
Channel Balance: 0.3 dB

Output Impedance: 100Ω

Balance headphone jack amp out:
SNR @MAX OUT 1kHz (A-wt): 132dB @1kHz

Dynamic Range @1kHz (A-wt): 132dB @1kHz
Frequency Response: 20Hz-20kHz (‡0.2dB) / 20Hz-40kHz (‡0.6dB)

Output Level: 12Vpp @G=L / 47Vpp @G=H
Channel Crosstalk: 121dB @1kHz

Output power:
10000mW × 2 @16Ω THD+N<1%
7080mW × 2 @32Ω THD+N<1%
4250mW × 2 @64Ω THD+N<1%
950mW × 2 @300Ω THD+N<1%
460mW × 2 @600Ω THD+N<1%

Dimensiuni
340 X 225 X 60 mm
Greutate

2,75 Kg
THD
THD+N @1kHz (A-wt): <0.00007% @Output=550mW (32Ω) / <0.00007% @Output=60mW (300Ω)

Accesorii incluse
Telecomanda dedicata

Manual de utilizare
Cablu de alimentare
Cablu optic
Cablu USB
