Amplificator integrat UNISON RESEARCH UNICO 150

Specificatii:


Output power:
150+150 W on 8Ω / 250+250 W on 4Ω;

Valves:
2X ECC83 2X 6H30;

Output stage:
Class AB thermostable, 8X Hexfet;

Input stage:
Pure A class, double triode totem pole ECC83;

Driver stage:
Pure A class, double triode totem pole 6H30;

Input:
6 line (3 unbalanced, 2 balanced, 1 “bypass” unbalanced);

Line Outputs:
1 tape, 1 sub  (volume controlled);

Frequency response:
-1dB @ 12Hz & 45kHz, -3 dB @ 6Hz & 80 kHz;

Input impedance:
24kΩ // 100pF;

Input sensitivity:
860mV RMS;

Output connectors:
4 + 4  bi-wiring;

Global Feedback factor:
0 dB;

Local Feedback factor:
16 dB;

THD:
< 0.005% @ 1kHz, 1 W < 0.002% @ 1kHz, 10 W < 0.003% @ 1kHz, 100 W < 0.002% da 20 a 20000 Hz, 150 W;

Output resistance:
<0.4Ω, resistive on all audio frequencies;

Power Consumption:
550 W (at max power on 8 ohm);

Dimensions:
43.5 cm x 18 cm x 44 cm;

Net weight:
25 kg.
