Preamplificator Electrocompaniet EC 4.8 Mk2

Specificatii:

• Number of channels: 2 ch
• Inputs: 2 BAL, 3 SE, 1 HT
• Outputs: 1 BAL, 1 REC OUT (fixed)
• Construction: Fully balanced, dual mono
• Input stage: JFET transistors
• Output stage: High Bias BJT transistors
• Volume control: Fully balanced
• Input impedance: 47 kOhm
• Input level: Single ended > 15 Vp-p
Balanced > 30 Vp-p
• Noise floor: < -130 dB
• Channel separation: > 120dB
• Frequency response: 0.5 − 200 kHz
• Gain: -111dB to +6dB
• Output impedance: 100 Ohms
• Output level: Single ended > 15 Vp-p
Balanced > 30 Vp-p
• THD + N: < 0,002%.
• Power consumption: 30 W
• Dimensions:
Width: 470 mm − 18.5”
Depth: 372 mm − 14.5”
Height: 80 mm − 3.14”
• Weight: 11.3 kg − 24.9 lbs
