Preamplificator Chord Electronics ULTIMA Pre

Specificatii:
Link producator:
https://chordelectronics.co.uk/product/ultima-pre/

Alte caracteristici:
Frequency Range: 2.5Hz – 200kHz +/- 3dB;
Total Harmonic Distortion: 0.002% 20Hz – 20kHz;
Intermodulation Distortion: -125dB on all inputs;
Signal to Noise Ratio: -117dB on all inputs;
Channel Separation: 20Hz @ 110dB, 1kHz @ 105dB, 10kHz @ 100dB, 20kHz @ 95dB;
Channel Balance: 0.01dB;
Input Max Voltage: 17v RMS Balanced – 8.5v RMS Unbalanced;
Output Max Voltage: 17v RMS Balanced – 8.5v RMS Unbalanced;
Output Offset: 0mV (Both Channels);
Potentiometer Performance: 0dB 0.5dB, -20dB 0.2dB, -60dB 0.24dB (13seconds Full Travel);
Nominal Gain: All inputs subject to six levels of switchable gain (x0.5, x1, x1.5, x2, x2.5, x3);
Input Impedance: 100 kΩ Balanced – 50 kΩ Unbalanced;
Output Impedance: 100Ω (Short Circuit Protected);
Operating Voltage: 85v – 270v AC (50Hz – 60Hz) Auto Switching;
Power Consumption: 60w;

Dimensiuni:
(W x D x H): 420 x 355 x 350mm;

Greutate:
30kg.
