Amplificator Integrat Advance Acoustic A10 APEX

Specificatii:


Output power 8Ω:
130W (THD+N 1%, 1kHz, 2 channels running);

Output power 4Ω:
198W (THD+N 1%, 1kHz, 2 channels running);

Frequency response (+/-1dB):
20Hz > 80kHz (31W, 8Ω);

Distortion:
0.045% (1kHz, 90W, 8Ω);

Signal-to-noise ratio:
106dB (1kHz, 90W, 8Ω);

AC input compatibility:
115/230V 50/60Hz;

Transformer type/power:
Toroidal / 380VA;

DAC:
ESS9018;

Digital inputs:
(3x) Optical: 24-bit - 192kHz PCM;
(1x) Coaxial: 24-bit - 192kHz PCM;
(1x) USB audio 24-bit/192kHz PCM - DSD64 - DSD128;
HDMI eARC: PCM Stereo;

A-BTC input:
For A-BTC Bluetooth receiver (optional);

Analogue inputs:
RCA LINE level (5x) - MM PHONO level (1x) + GROUND;
XLR Line level (1x);

Analogue outputs:
RCA: REC-OUT (x1), PRE-OUT (x1), SUB-OUT (x2);

Headphone jack:
6.35mm jack;

High Bias:
Yes, ON/OFF switch;

Update:
Via USB key on ‘UPDATE’ port;

Speaker terminals:
(2x) Screw terminals compatible with bare cable, spade and banana plugs;

Remote control:
Infrared, REM-19, compatible with A10 APEX and ACD;

Trigger jack:
(2x) Input and Output, 12V;

Product dimensions (WxHxD in cm):
43x17.5x35.1;

Packaging dimensions (WxHxD in cm):
54.6x30.3x49.4;

Gross weight (kg) / Net weight (kg):
16.3 / 12.9;

Model no.:
A10 APEX 30TH EDITION.
